Nanjing Huozao Machinery Technology Co., Ltd. is one of the leading manufacturers and suppliers of herbal grinding machine in China. With abundant experience, we are committed to providing high quality equipment made in China with competitive price. Welcome to wholesale customized herbal grinding machine from our factory.
Design Adaptation for Rhizome Herbal Characteristics
Rhizome Chinese medicinal materials have two distinct physical traits that affect crushing results. Hard lump materials like Panax notoginseng and kudzu root feature compact and solid textures, while licorice and astragalus contain abundant tough fibers. Ordinary toothed disc pulverizers depend on simple grinding and friction, which often fail to balance crushing quality and efficiency for these herbs, easily causing incomplete crushing, uneven powder size and leftover material residue. This Herbal Grinding Machine is redesigned to solve these common on-site processing problems.
Different from toothed disc models that rely solely on grinding friction, this pulverizer uses shearing and impact as its main crushing forces. Field processing trials and material property tests prove that shearing-based crushing works better for fiber-containing herbal structures. It cuts off scattered fibrous strips thoroughly and improves particle uniformity, producing stable, high-quality finished powder.
Multi-Type Replaceable Blade System
The Herbal Grinding Machine supports flexible blade replacement to realize multi-scene processing with one device. Operators can switch blade types according to the raw material's hardness, fiber content and lump state, matching different processing requirements for various root and rhizome herbs:
Hammer Blades Ideal for high-fiber medicinal materials, including various plant roots, stems, leaves and barks. This blade type delivers high throughput and fine powder quality, making it the most commonly used option for daily processing of regular root and tuber herbs.
Cross-Shaped Hammer Blades Suitable for high-hardness lump medicinal materials. With strong impact crushing performance, it handles solid raw materials such as Panax notoginseng and kudzu root effectively, fully breaking hard blocks without coarse particle residue.
Toothed Disc Blades Serve as universal blades for general scenarios. They fit most conventional root and tuber medicinal materials, delivering steady output and uniform powder fineness for standard daily herbal crushing production.
Features and Suitable Use Cases
|
Feature Categories |
Specify |
|
Processing capacity matching |
Different specifications are available to meet various production requirements, covering a full range from laboratory-scale small-production models to industrial-scale production models. |
|
Fine adjustment possible |
The fineness of finished products typically ranges between 20–200 mesh, with flexible adjustment achievable by replacing screens of different pore sizes. |
|
Cleanliness and Environmental Protection |
Most models are constructed from 304 stainless steel, complying with GMP standards; some models feature integrated dust removal systems (such as cyclone separators and pulse-jet dust collectors) to ensure a dust-free grinding process. |
|
Feature Expansion |
Some models can be equipped with a water-cooling jacket to control the crushing temperature rise, making them suitable for heat-sensitive rhizome materials. |
