Nanjing Huozao Machinery Technology Co., Ltd. is one of the leading manufacturers and suppliers of plant pulverizer in China. With abundant experience, we are committed to providing high quality equipment made in China with competitive price. Welcome to wholesale customized plant pulverizer from our factory.
Core Design Ideas for Plant Material Processing
Most plant raw materials bring two key processing difficulties during crushing. Many plants contain rich crude fibers that are hard to cut and prone to winding and residue. Some seed and fruit materials carry natural oil and sugar components, which easily turn sticky and adhere to equipment during high-speed processing. This pulverizer is structurally optimized targeting these two common pain points, focusing on efficient fiber cutting and effective temperature control to ensure stable crushing quality.
Optimized Crushing Mode
Different from toothed disc pulverizers that mainly depend on grinding and friction, this plant pulverizer adopts a mixed processing mode dominated by shearing and assisted by impact force. Matching movable and fixed blade sets are installed inside the crushing chamber. When materials enter the equipment, high-speed rotating blades cooperate with fixed tooth rings to produce continuous shearing and impact force, which cleanly cuts off messy plant fibers and avoids uncrushed residual strips.
For high-oil and high-sugar plant materials that are prone to adhesion, upgraded specialized models are available. These versions support both dry and wet grinding processes, and can be fitted with circulating water cooling jackets. Real-time heat dissipation effectively controls cavity temperature rise, preventing material softening, sticking and deterioration caused by accumulated heat.
Flexible Fineness Adjustment
The plant pulverizer supports wide-range adjustable finished particle size to match different production standards. Operators can replace screen meshes of different apertures or fine-tune the gap between the grading wheel and grading disc. The adjustable fineness range covers conventional coarse and fine powder from tens of meshes to hundreds of meshes, and can even achieve ultra-fine powder processing, adapting to diversified finished product requirements of plant raw material deep processing.
Features
|
Feature Categories |
Specify |
|
Wide material compatibility |
Capable of processing a wide variety of plant materials, including fibrous materials (herbal medicines, straw), brittle materials (grains, legumes), and oil-or sugar-containing materials (nuts, certain fruits). |
|
Cooling design to prevent adhesion |
To address the heat generation issue that occurs during the crushing process of plant materials, many models come standard or are available as optional configurations with a water-cooled jacket, which uses circulating water to dissipate heat, thereby preserving the material properties and preventing adhesion. |
|
Cleanliness and Environmental Protection |
The contact areas with materials are predominantly constructed from 304 stainless steel, complying with GMP standards; many units integrate cyclone separation and dust removal systems to achieve dust-free production. |
|
Capable of handling fresh materials |
Certain specialized models (such as mechanical grinding mills) can even process fresh green plants and high-water-content residues, grinding them into dry powder or slurry. |
Technical Parameter Reference
There are a vast number of models and specifications available for plant shredders; below are the parameter ranges for two typical models, which can serve as a reference for model selection:
|
Device type |
Production range (kg/h) |
Fineness range (mesh) |
Power Range (KW) |
Features Overview |
|
WFJ Series (Ultrafine Grinding) |
80 - 300 |
80 - 320 |
17.5 |
Suitable for ultrafine grinding of plant materials with stringent fineness requirements. |
|
WF Series (General Purpose) |
10 - 2000 |
40 - 120 |
2.2 - 55 |
The product range spans from experimental prototypes to mass production, offering high versatility. |
Note: The above production capacity and fineness values are for reference only; the actual performance is significantly influenced by the properties of the raw materials (such as moisture content and fiber content). When selecting equipment, it is recommended to confirm with the manufacturer based on the specific material characteristics.
