Nanjing Huozao Machinery Technology Co., Ltd. is one of the leading manufacturers and suppliers of pharmaceutical tablet coater in China. With abundant experience, we are committed to providing high quality equipment made in China with competitive price. Welcome to wholesale customized pharmaceutical tablet coater from our factory.
Main Components
The pharmaceutical tablet coater has a modular structure. The coating drum is made of 304 stainless steel with a polished inner surface to reduce tablet scratching and material buildup. A spray system applies coating liquid evenly across the product surface. A hot air circulation system dries the coating layer and keeps process conditions stable. The unit includes an exhaust system and dust collection components. A variable-frequency drive controls the drum speed. The control system allows operators to adjust and monitor other key process parameters.
Features
The coating layer is uniform, giving tablets a smooth appearance and reducing variation between batches. The sealed chamber limits dust escape and supports cleaner production. Spray volume, drum speed and drying temperature can be adjusted independently for different process needs. The design reduces tablet breakage and coating material waste. Routine maintenance is straightforward. The control interface is simple to operate.
How It Works
During operation, tablets tumble continuously inside the rotating coating drum. The spray system applies atomized coating liquid onto the moving tablet surfaces. Heated air circulates through the drum to dry the coating layer. Dust and solvent vapors generated during the process are drawn into the exhaust and filtration system.
Technical parameters
|
Model |
BG-150 |
|
Customization Supported |
Yes |
|
Origin |
Nanjing |
|
Air Consumption |
≤106kg/h |
|
Machine Noise |
≤75dB, enclosed soundproof air duct |
|
Core Advantages |
High coating yield, airtight, clean and environmentally friendly, GMP compliant |
|
Drum Speed |
3-24r/min |
|
Peristaltic Pump Motor Power |
0.18kw |
|
Feeding Port Diameter |
Φ475mm |
|
Sales Location |
Nationwide |
|
Material |
Stainless Steel |
Applications
This pharmaceutical tablet coater is suitable for pharmaceutical, nutraceutical and food processing facilities. It can handle film coating, sugar coating and color coating for tablets, pills and granular products.
