Nanjing Huozao Machinery Technology Co., Ltd. is one of the leading manufacturers and suppliers of three-dimensional mixer in China. With abundant experience, we are committed to providing high quality equipment made in China with competitive price. Welcome to wholesale customized three-dimensional mixer from our factory.
Main Components
1. Heavy-Duty Frame
The machine is built on a reinforced steel frame that supports the mixing drum and transmission system. The rigid construction helps keep the equipment stable while the drum moves in multiple directions. It also helps control vibration and operating noise during continuous use.
2. Three-Dimensional Drive System
A dedicated transmission system controls the movement of the mixing drum. During operation, the drum performs combined rotation, translation, and swinging movements. The different movement directions continuously change the material flow inside the chamber.
The drive system is designed for stable operation and can be configured according to the required mixing speed and production conditions.
3. Stainless Steel Mixing Drum
The mixing drum is manufactured from stainless steel and has a smooth polished inner surface. The rounded internal corners help reduce areas where powder or granules can remain after mixing.
The relatively simple chamber design also makes the equipment easier to clean between batches, which is useful for applications involving frequent product changes.
4. Control System
The control panel provides basic start/stop operation and timer settings. A variable-frequency drive can also be used when the mixing speed needs to be adjusted for different materials or production requirements.
Features
High Mixing Uniformity
The mixing drum changes its movement direction continuously, causing the materials to follow different paths inside the chamber. Powder and granule particles are lifted, dispersed, and redistributed during operation.
This movement is helpful when processing materials with different particle sizes or densities and can reduce the risk of separation during mixing.
High Loading Efficiency
The mixer is designed to handle a relatively high filling ratio. More material can be processed in one batch, which can be useful for production lines that need to balance batch capacity and mixing time.
The actual loading capacity depends on the bulk density, particle characteristics, and other properties of the material being processed.
Easy Cleaning and Maintenance
The polished stainless steel mixing chamber has a simple internal structure and fewer areas where material can accumulate. This makes routine cleaning more convenient, especially when different materials are processed on the same machine.
The product-contact chamber is also separated from the main drive section, helping reduce the possibility of lubricant or mechanical contaminants entering the material area.
Working Principle
The Three-Dimensional Mixer works by moving the mixing drum through a combination of rotation, translation, and swinging. Instead of forcing the material to follow one circular path, the drum changes the direction of movement continuously during operation.
As the drum moves, the material inside is carried upward, falls back through the powder bed, and moves toward different areas of the chamber. Repeated changes in material position allow particles to come into contact with one another from different directions.
For powders and granules with different particle sizes or densities, this movement can help distribute the material more evenly and reduce segregation during the mixing process.
Unlike mixers that rely on complicated internal blades or agitators, the Three-Dimensional Mixer mainly uses the movement of the drum itself to create material circulation. This makes the internal chamber relatively simple and convenient for cleaning and batch changes.
Technical parameters
|
Model specifications |
Barrel volume (L) |
Maximum loading capacity(KG/batch) |
Spindle speed (R/MIN) |
Motor power (KW) |
|
SYH-5 |
5 |
8 |
0 - 15 |
0.55 |
|
SYH-50 |
50 |
20 |
0 - 13 |
1.1 |
|
SYH-100 |
100 |
40 |
0 - 14 |
1.5 |
|
SYH-200 |
200 |
80 |
0 - 12 |
2.2 |
|
SYH-400 |
400 |
160 |
0 - 12 |
4 |
|
SYH-600 |
600 |
240 |
0 - 11 |
5.5 |
|
SYH-800 |
800 |
320 |
0 - 10 |
7.5 |
|
SYH-1000 |
1000 |
400 |
0 - 9 |
7.5 - 15 |
