Working Principle
Simply put, microwaves provide a highly efficient heat source, while a vacuum provides a low-temperature evaporation environment. The combination of these two achieves a balance between high efficiency and gentle heat transfer.
Microwave Effect: Microwaves can penetrate materials and act directly on the polar molecules within them. This "volume heating" method overcomes the bottleneck of traditional drying methods, which suffer from slow heat conduction due to the lack of air as a medium in a vacuum environment.
Vacuum Pressure Reduction Drying: Within a sealed chamber, the vacuum system reduces the pressure to a negative pressure state. According to the laws of physics, the boiling point of water decreases as pressure decreases. This allows the moisture in the material to rapidly vaporize and evaporate without undergoing high-temperature boiling, achieving low-temperature drying.
Features
High Drying Efficiency: Because microwave energy acts directly on the material's interior, the drying speed is 4 to 20 times faster than conventional methods.
Low-Temperature Protection: Low-temperature drying maximizes the preservation of active ingredients, color, and flavor.
Highly Uniform Drying Quality: Minimally Small Temperature Difference: Because the material is heated simultaneously inside and out, the "burnt outside, uncooked inside" phenomenon of traditional drying is avoided.
Selective Heating: Different heat absorption in dry and wet areas contributes to the uniformity of the final moisture content of the material.
Energy Saving and Environmental Protection: Low heat loss, saving over 50% in energy consumption.
Product Structure
|
System Modules |
Main Components and Functions |
|
Microwave Generator System |
Includes a magnetron (generating microwaves) and a waveguide (transmitting microwaves). Core components are typically designed with industrial-grade water/air cooling to ensure continuous operation over extended periods. |
|
Vacuum System |
Contains a vacuum pump (water ring pump or rotary vane pump) and a pressure sensor to maintain a high vacuum within the chamber. |
|
Drying Chamber |
Mostly constructed of 304 stainless steel in a single welded piece, corrosion-resistant and easy to clean. It contains a rotating feed tray or multiple fixed feed trays. |
|
Measurement and Control System |
Employs non-contact infrared temperature measurement (avoiding interference with the vacuum environment) combined with a PLC control system to achieve closed-loop PID automatic adjustment of microwave power. |
|
Safety Interlocks |
Features multiple safety measures including door-opening power-off protection, microwave leakage prevention device, and overload protection. |
Applications
Microwave vacuum drying ovens are widely used in various industries such as food, pharmaceuticals, chemicals, agricultural products, building materials, battery materials, leather, and industrial ceramics. They are particularly suitable for processing high-value-added, heat-sensitive materials, such as health products, medicinal herbs, fruits and vegetables, and chemical raw materials, for dehydration, low-temperature concentration, sterilization, and preservation.
In the pharmaceutical field, this equipment is commonly used for drying traditional Chinese medicine pills and extracts, offering advantages such as low energy consumption, high material recovery rate, and small footprint.
